种类与简单介绍/Brief Introduction：

该设备是结合在一起胶囊液夹丝塑瓶的新护肤品，根除完美解决了往往胶囊液夹丝塑瓶的黑心目的。用此灌封机所有的塑瓶，才能不要洗瓶机、烘干箱机，更不要消毒液，是可以简单灌封。该设备全系统自动理瓶、进瓶、包装，包装量比较稳定的，无漏滴，无瓶不包装。上盖、封口处率可以达到100%。此机系统领先，表面积小、运作比较稳定的、噪声污染低，控制维护、家电清洗不便等优缺点，截然非常符合GMP的标准。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本款式有减速和高速路哪几种总产量供您确定。Note: this model has two kinds of low speed and high-speed production for your choice.

的特点 Characteristic

◆机器适合于各项易折瓶服用液压力容器检验分装和封好。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆一切电嚣pcb板均采用了知名品店牌的品牌。All electrical components adopt famous brand◆远程服务器操作步骤更直观非常方便，无瓶不装罐，计量检测*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折材料瓶灌封机的常见机构与的工作原理Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型口服方式液易折塑胶片瓶灌封机注意理瓶器、理盖器、主传动系统设计操作系统、此次带缝隙送小瓶置、瓶子检漏系统设计、罐装构造、去除系统设计、熔接封构造、汽动机械性小指夹瓶构造、伺服线束高压电机缝隙上瓶构造与出瓶构造等组成部分。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆工具选择的服用液易折塑瓶、盖有的是定美观区制作的，是指药袋材同意证，因而瓶身与底盖经传播和"去开发"后可直接的来到灌封间。经过理盖器、理瓶器的全自动定项分类整理，删去选择性底盖及瓶身底口朝下的瓶，使定项后的包材喂料有制度地来到运送滑槽中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆专向后服食液易折橡胶瓶在输送带钢轨里排Directional oral liquid after folding plastic bottles in conveying rail out easily

系统因素technical parameters：

型号model	NLGFY-40	NLGFY-80
装量范围图The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封口处率Hot sealing intensity	》99%
装量误差值The load error	《1.5%
破埙率damage rate	《1.0%
工率power	2KW	3KW
电压Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
重量体积 Weight	700Kg	800Kg
