用处与介绍/ Brief Introduction：

本生產线由全自行理瓶机、滚筒设备式洗瓶机、灭菌处理变干机、眼蓝药粉装灌设备旋盖机、旋转式贴标签签热泵机组成，可顺利完成理瓶、水、气的家电清洗、干燥及臭氧的危害紫外线消毒、装灌设备、加塞、旋盖、贴标签签等工艺，最主要的应用在眼蓝药粉试述他小残留量硫酸铜溶液的联线生產，也可单人自主运行。仍然不符合GMP规定。This production line consist of  Automatic Bottle Unscrambler,  Bottle Washing Machine, Tunnel Type Sterilization Drier, eyedrop filling machine, Vertical Labeling machine, can complete bottle sorting, water,and gas cleaning, drying and ozone disinfection, filling, plugging, capping, labeling, mainly used in eyedrops and other small doses of solution, also can be used single independently.　 Meet the GMP requirement.

特色/Characteristic：

超声波焊接机组定制机构科学合理，运营平稳、罐装定位精更高，具中国国内竞争对手业好水平方向。彻底具有GMP规则。     眼蓝药水装罐旋盖机犹是我企业的最后代企业产品，组排菜单栏管控，颤动泵装罐，由真空度吸机诫手带换节流阀比较好的打塞，要确保了平衡性和达标率。用于恒发动机功率旋盖，享有无瓶不装罐、无塞不上盖，无瓶无塞可自己宕机的功用。    It with reasonable structure, higher precision in filling, reaching the advanced level in domestic same business. Meet with requirement of GMP standard completely.eyedrop filling capping machine is a third generation product, human-machine interface operation, filling by peristaltic pump, replace air cylinder with vacuum drived manipulator for plugging, aquire higherstability and percent of pass. Constant torquecap screwing. No bottle no filling, no plug no capping and automatically stop if cap and plug is under-supply.

系统指标/technical parameters：

适用于型号/Bottle size	10-20ml
种植学习能力/Capacity	40-60瓶/分  70-120瓶/分 40-60/  70-120 bottles/min
使用水重压/ Hydraulic Pressure Mpa	0.3Mpa
使用出水量 /water consumption	0.5 m3/h
洁净车间收缩环境水压 /Clean compressed air pressure	0.6-0.8Mpa
洁净室文件压缩气氛容量/Clean compressed air consumption	300 L/min
电源线/Voltage	380V/50Hz
热效率/Power	5.5 kw
产生线总长/Dimension	11000*1500*1900mm
